Cytron 10Amp 7V-30V DC Motor Driver (Potentiometer/Switch/MCU Control)

MD10-POT is 10A continuous load and 30A peak load high quality motor driver or speed controller that enables you to easily control a motor's run/brake, direction and speed.

The driver can be controlled directly using 3 methods:.

• MCU (Arduino/Raspberry/STM/TIVA C) automatic control using PWM, DIR and GND pins
• Potentiometer manual control (motor speed direct control)
• Switch manual control (motor direction of rotation direct control)







 Features

• Bi-directional control for 1 DC motor.
• Support motor voltage ranges from 7V to 30V.
• Maximum current up to 10A continuous and 30A peak (10 second).
• 3.3V and 5V logic level input.
• Solid state components provide faster response time and eliminate the wear and tear of mechanical relay.
• Fully NMOS H-Bridge for better efficiency and no heat sink is required.
• Speed control PWM frequency up to 10KHz.
• Support both locked-antiphase and sign-magnitude PWM operation

Dimension: 81mm x 48mm

Package Includes:

• 1 x MD10-POT
• 1 x 10kOhm Potentiometer with connector
• 1 x 3-Way Rocker Switch with connector
• 1 x Quick Start Guide Card
